P series Laser WUXGA 7000lm Projector
The Sharp P701U is a premier entry installation LCD laser projector designed to meet the needs of higher education and corporate users. At 7000 lumens, WUXGA resolution and outstanding LCD color fidelity the P Series delivers impressive looking images in all kinds of demanding applications.
Super silent yet brilliantly versatile
The Sharp P701U projector carries Sharp’s patented IP5x sealed LCD cooling system which eliminates the need for a filter and combined with the maintenance free laser light source, this projector is as close to set-and-forget as you will find in projection. The benefit of Sharp’s advanced cooling system is whisper quiet operation that eliminates the distraction that can sometimes be caused by a more noisy projector. Enjoy time-saving installation flexibility with broad horizontal and vertical manual lens shift, a 1.6x manual zoom lens, roll free capability and HDBaseT input.
Benefits
- IP5x sealed cooling system provides a filter-free projection solution
- Whisper quiet operation for minimal distraction
- LCD, laser technology delivers an impressive and color accurate image
- Manual horizontal & vertical lens shift enables flexible projector placement
- Built-in HDBaseT input provides a single connection for video, audio and control
- 4K Ready - Display stunning 4K UHD 30Hz content using Sharp's proprietary high performance video processing/scaling chip
- Supports 21:9 aspect ratio for more engaging meeting spaces
- Eco-friendly features, minimal maintenance and a cost saving design mean these projectors are great for demanding applications in higher education classrooms and corporate conference rooms
- Projection Technology
- 3LCD Technology
- Native Resolution
- 1920x1200
- Aspect Ratio
- 16:10
- Contrast Ratio (typ.)
- 3,000,000:1
- Brightness (Lumen)
- 7000 Lm Normal / 7400 Lm Center / 6300 Lm Silent Mode; compliant with ISO21118-2020
- Light Source
- Laser
- Light Source Life
- 20,000 hrs
- Lens
- F= 1.6–2, f= 15.3–24.6 mm
- Lens shift
- H:±20, V:+44,-0
- Keystone correction
- +/- 30° manual horizontal / +/- 30° manual vertical
- Projection Factor
- 1.08–1.76:1
- Projection Distance (m)
- 0.8 – 12.9m
- Screen Size (diagonal)
- Maximum: 762 / 300"; Minimum: 76 / 30"
- Zoom
- Manual; x1.6
- Focus Adjustment
- Manual
- Digital Input
- 1 x HDBaseT; 2 x HDMI™ supporting HDCP
- Audio Output
- 1 x 3.5 mm Stereo Mini Jack (variable)
- Input Control
- 1 x D-Sub 9 pin (RS-232) (male)
- LAN
- 1 x RJ45
- USB
- 1 x Type B (for Service); 1x Type A (USB 2.0 high speed) with 2.0A Power Supply
- Remote Control
- Aspect Ratio; Audio Control; Auto Adjust; AV Mute; Digital Zoom; Eco Mode Control; Freeze; Freeze-function; Help-function; ID set; Keystone Correction; Magnify-function; Page (up, down); Picture Adjust; Picture Mute; Power (On-OFF); Select (up, down, left
- Power Supply
- 100-240 V AC; 50 - 60 Hz
- Power Consumption
- 365 Normal / 330 Silent Mode / 1 Network Stand-by / 0.4 Stand-by
- Operating Temperature
- 5ºC to 40ºC
- Operating Humidity
- 20% to 80%
- Storage Temperature
- -10ºC to 50ºC
- Storage Humidity
- 20% to 80%
- Dimensions (W x H x D) [mm]
- 480 x 122 x 407 (without lens and feet)
- Weight [kg]
- 9.7
- Fan Noise [dB (A)]
- 31 / 22 (Normal / Silent)
- Colour Versions
- White
- Safety and Ergonomics
- CE; ErP; RoHS; RCM; TUEV Type Approved
- Built-In Speaker
- 1 x 20 (mono)
- Special Characteristics
-
AMX Beacon; Auto Power ON/OFF; Carbon Savings Meter; Constant Brightness Mode; Control ID Function; Crestron Connected; Direct Power-Off Function; Free Tilt; HDBaseT; HTTP Browser Control; Kensington security slot; Keypad Lock; Light Source Adjustment; Magnify; NaViSet Administrator 2; Optional User Logo; OSD with 25 languages; Password Security System; PJ LINK; Portrait Setting; Quick Start; Source Select with Beep Function; Test Pattern; Unique Power Saving Functions; USB Viewer
- Ecological Standards
- ErP compliant; RoHs compliant
- Ecological Materials
- Downloadable manuals; ECO packaging
- Shipping Content (Accessories)
- 2x AAA Batteries; IR Remote Control; Power Cord; Projector; Quick Setup Guide; Security Sticker; Users Manual
