65-inch 4K SoC 16/7 Digital Display
PNHB651

65-inch 4K SoC 16/7 Digital Display

Versatile High-definition Signage with Built-in SoC ControllerThe PN-HB651 is a monitor you can trust to get your message out there. What sets it apart is a built-in system-on-a-chip (SoC) controller that allows it to deliver digital signage straight out of the box.

  • Built-in SoC (System on Chip)
  • Support for H.265/HEVC
  • SHARP Open Architecture Platform
  • Smart Connectivity
  • Autoplay with Media Player
  • Web-Based Signage
  • Bundled SHARP Content Distributor software
  • 4K LCD Panel
  • Flexible installation options
  • 16/7 Operation


Clearly a better choice

Showcase your content in the best possible way with superior display features

You can enjoy the perfect combination of slim and stylish design and crystal clear pictures with this unit from Sharp. You can get your message across loud and clear, wherever it needs to be seen.

This true 4k Ultra HD (3840 x 2160) resolution is four times the resolution of 1080p Full HD. It means on-screen content, including movies and still images, is rendered in superbly realistic detail and depth.

This is further enhanced by innovative LED backlighting, which ensures vivid colours and boosted contrast for sharper text and beautifully textured graphics.

Flexibility as standard

This unit can be installed in a variety of ways, including portrait, landscape and flat facing upwards, so you can select the most effective mode to display your content. This flexibility means you can use it for a wide variety of applications in office environments, meeting rooms and educational settings.

Displays that accommodate your every need

Enjoy the flexibility of showcasing variable content at a time that suits you

Different business environments require different display operating times, and that’s not a problem. This display can operate 16/7, ideal for shopping centers or large corporate offices that can accommodate some downtime.

Screen Size
65-inch
Panel Type
TFT LCD
Max. Resolution
3,840 x 2,160 pixels
Max. Display Colours
1,070 million colours
Pixel Pitch (H x V)
0.372 × 0.372 millimetre
Max. Brightness (average)
350 cd/m2
Contrast Ratio
5,000 : 1
Viewing Angle (H/V)
178°/ 178°(CR ≧ 10)
Active Screen Area
1,428.48 × 803.52 millimetre
Response Time
9.5 ms (gray to gray, avg)
Backlight
Direct Lit LED
Built-in
10 W + 10 W
Mounting
4 points, 400 × 400 mm pitch, M6 screw
Power Supply
100V - 240V AC, 50/60 Hz
Power Consumption
260 watts
Dimensions (W x D x H) (approx, display only)
1,455 × 88 × 830 millimetre
Weight
29 kilogram
Operating Humidity
20% to 80% RH (No condensation)
Main Accessories

AC power cord, remote control unit, battery (AAA size) × 2, CD-ROM, set-up manual, cable clamp (insertion type) × 2, cable clamp (stick-on type) × 3, USB flash drive/microSD card cover, USB flash drive/microSD card cover fixing screw, logo sticker, wirele

Installation

Face-up
Landscape
Portrait

Video
Analogue RGB (0.7 Vp-p) [75Ω], DisplayPort™ 1.2, HDMI™
Synchronisation
Horizontal/vertical separation (TTL: positive/negative)
Plug & Play
VESA DDC2B
Standard
Analogue RGB (0.7 Vp-p) [75Ω], DisplayPort™ 1.2, HDMI™
Options
PN-ZB03PC, PN-ZB03W, PN-ZB03H
DisplayPort™
1
HDMI™
2
PC Analogue mini D-sub 15 pin
1
RS-232C
In / out
USB
3
Audio (3.5mm stereo mini jack)
1
Options
PN-ZB03H : HDBaseT™ x 1, or, PN-ZB03W : LAN x 1 (10Base-T/100Base-TX), Wireless adapter x 1 (USB 2.0)
DisplayPort™
1
3.5mm mini stereo jack
1

Business Products Warranty Statement

This Sharp product is warranted against faults in material and manufacture for 36 months.

In the event of any defect arising in the equipment during the warranty period, such repairs should only be carried out by the Dealer from which the unit was originally purchased or a Service Centre approved by Sharp to service this type of equipment These repairs would be carried out at no charge to the owner, subject to the conditions specified herein.

This warranty does not extend to defects or injuries caused by or resulting from causes not attributable to faulty parts or the manufacture of the product, including but not limited to, defect or injury caused by or resulting from misuse, abuse, neglect, lack of maintenance, accidental damage, improper voltage, liquid spillage, vermin infestation, software, or any alterations made to the product which are not authorised by Sharp.

Please retain your sales documentation, as this should be produced to validate a warranty claim. This warranty is in addition to and in no way limits, varies or excludes any implied rights and remedies under any relevant legislation in the country of sale.

Goods presented for repair may be replaced by refurbished goods of the same type rather than being repaired. Refurbished parts may be used to repair the goods. The repair of your goods may result in the loss of user generated data, please ensure that you have saved this data elsewhere prior to repair.

Australian Customers
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. The criteria of a major failure is defined in the Australian Consumer Law. Should you require any assistance with a major failure please contact Sharp Customer Care.
