MultiSync® PN-UN553S 55" Video Wall Display
The 55-inch Sharp MultiSync® UN553S draws on its heritage of engineering excellence to deliver a premium experience yet at remarkable value. Purpose-designed with ultra-narrow bezels to create high-resolution video walls with minimal image interruption.
Seamless video walls to amplify your brand
Advanced intelligent features and imaging performance powered by SpectraViewTM ensure precise and consistent visualisation across the entire wall, The 55-inch Sharp MultiSync® UN553S creates the impression of a single, continuous surface for clear and engaging content presentation.
Engineered for 24/7 operation in public spaces, the series combines robust metal construction with advanced thermal management to deliver reliable, long-lasting performance. It delivers uncompromising quality and dependable operation for demanding applications in corporate and transportation environments and for mission-critical control room scenarios.
Benefits
- Easy installation – effortlessly set up you wall display with Auto TileMatrix and out-of-the-box calibrations. Save time by plugging in ready-to-use image presets for predefined application scenarios.
- Enhanced imaging performance – advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.
- Lifelike and consistent colour – expect colour reproduction that feels true to life with IPS panel technology, the top choice when it comes to colour consistency. The S-IPS panel ensures that perfect visibility is maintained in landscape and portrait mode and at extreme viewing angles as viewers pass by.
- Secure Reliability and Longevity of Video Walls – unique NEC heat management system enables the user to monitor and control the heat inside the display.
- Cost Saving Device Management – save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
- Panel Technology
- IPS with Direct LED backlights
- Screen Size
- 55 inch
- Aspect Ratio
- 16:9
- Max. Brightness (average)
- 700 cd/m2
- Contrast Ratio
- > 3500:1
- Viewing Angle (H/V)
- 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
- Colour Gamut
- 72% of NTSC
- Response Time
- 8ms
- Panel Refresh Rate (Hz)
- 60Hz
- Haze Level (%)
- 25
- Supported Orientation
- Landscape, Portrait
- Native Resolution
- 1920 x 1080
- Supported Resolution
- 1024 x 768; 1080i; 1080p; 1280 x 1024; 1280 x 768; 1360 x 768; 1600 x 1200; 1920 x 1080; 3840 x 2160; 640 x 480; 720p (50/60 Hz); 800 x 600
- Horizontal Frequency [kHz]
- 26 - 134
- Vertical Frequency [Hz]
- 23 - 86
- Input Video Analogue
- 1 x VGA; Composite (RCA)
- Input Video Digital
- 1 x DVI-D (with HDCP); 1 x OPS Slot; 2 x DisplayPort (with HDCP); 2 x HDMI (with HDCP)
- Input Audio Analogue
- 2 x 3.5 mm jack
- Input Audio Digital
- 2 x DisplayPort; 2 x HDMI
- Input Control
- 1 x Remote Control (3.5 mm jack); 1 x RS232; 2 x LAN 100Mbit
- Input Data
- 1 x microSD (MediaPlayer); 1 x USB 1.0 (Downstream); 1 x USB 1.0 (MediaPlayer); 1 x USB 2.0 (Upstream); 2 x USB 1.0 (Compute Module, 1 x 5V/2A powered)
- Output Video Digital
- 1 x DisplayPort (loop through: DisplayPort, OPS slot-in PC); 1 x HDMI (loop through: HDMI, OPS slot-in PC, Mediaplayer)
- Output Audio Analogue
- 1 x 3.5 mm jack
- Output Control
- LAN 100Mbit
- Factory Calibration
- Gamma; Intensity; RGB; Uniformity; White Point
- Sensor Calibration (through USB)
- PC-less Calibration with USB Sensor MDSVSensor3; White Copy (post self-calibration)
- Calibration with Software
- Corner Uniformity; Gamma; Intensity; RGB; Update Factory Calibration; Update Uniformity Correction; White Point
- Calibration Software
- Display Wall Calibrator
- OPS Slot
- Slot Technology: Open pluggable specification (NEC / Intel OPS standard)
- OPS Max. Current / Power Consumption [A / W]
- 3.6 / 58
- Human Sensor
- Optional, external, 4-5m range, triggered actions programmable
- Temperature Sensor
- Integrated, 3 sensors, triggered actions programmable
- NFC Sensor
- Integrated, 2cm range, free NEC Android App required
- Power Consumption
- 180W shipping
- Power Savings Mode
- < 0.5; < 2 (Networked Standby)
- Operating Hours
- 24/7
- Operating Temperature
- 0ºC to 40ºC
- Operating Humidity
- 20% to 80%
- Storage Temperature
- -20ºC to 60ºC
- Storage Humidity
- 10% to 90%
- Weight [kg]
- 28.1
- Bezel Width [mm]
- 0.44 bottom/right; 0.44 top/left; 0.88
- Dimensions (W x H x D) [mm]
- 1,210.5 x 681.3 x 103
- VESA Mounting [mm]
- 4 holes; 400 x 400 (FDMI); M6
- Accessories
- Calibration kit (KT-LFD-CC2); Overframe kit (KT-55UN-OF5); Remote control kit (KT-RC3)
- OPS Slot
- Intel® Atom, Celeron and Core i3, i5, i7 Slot-in PCs
- Energy Efficiency
- Carbon savings meter; Energy consumption: 146 kWh/1000 h; Energy efficiency class: G; Human sensor; LED backlight
- Supported Image Formats
- JPG (baseline, progressive, RGB, CMYK); max. resolution 5000 x 5000; PNG (interlace, alpha channel); max. resolution 4000 x 4000
- Supported Video Formats
- MP4 / MOV / FLV (video H.264, audio MP3, AAC); max. resolution 1080p at 30 Hz, 1080i at 60 Hz; MPG (video mpeg1/2, audio mpeg audio layer2/3, AAC-LC); MP @ ML, MP @ HL; WMV (video H.264, wmv advanced L3, wmv simple / main, audio mp3 wmv std); max. resolut
- Supported Audio Format
- MP3 (MP3); max. bit-rate 320 kBit/s; WAV (LPCM); max. 48 kHz sampling
- Safety and Ergonomics
- BSMI; CE; EAC; EMC Class B; FCC; PSB; RCM; REACH; RoHS; SASO; TÜV GS; TÜV S; UL/C-UL; VCCI
- Pixel Failure Class
- ISO 9241-307, Class 2
- Special Characteristics
- Auto ID assignment; Auto tiling function; Automatic Alarm E-Mails; DICOM Simulation; Frame Comp; HTTP Server; Image flip; NaViSet Administrator 2 - free download; PJLink Support; TileMatrix; USB Media Player; User input priority definition; User readable
- Colour Versions
- Black Front Bezel, Black Back Cabinet
- Audio (Speakers)
- Optional Speakers (15 W + 15 W)
- Shipping Content (Accessories)
- Display; DisplayPort Cable; HDMI Cable; LAN cable (RJ45); Power Cable
