MultiSync® M751 75" Large Format Display
M751

MultiSync® M751 75" Large Format Display

For economical signage in 24/7 commercial environments, the 75” MultiSync® M751 delivers all the professional performance and features you need, whilst minimising the cost of ownership.

With a 500 cd/m2 brightness output and anti-glare panel, the viewer enjoys excellent visual quality unhindered by reflections, with a slim, aesthetic design for unobtrusive integration.

POA

Intuitive professional content delivery

Great first impressions can make all the difference; presenting your business in the best possible way will boost your brand. With slim, modern styling, 24/7 operation and high haze panel to reduce reflections when ambient light is high, the M series is the professional way to deliver your message, yet at an attractive price point.

With the optional MediaPlayer or the more powerful Intel® Smart Display Module (Intel® SDM) computing device, you are primed and ready for intuitive signage creation delivering real-time media playback for exceptional visual experiences. For advertising, infotainment and meeting room applications, the M Series provides powerful, upgradable functionality and all the aesthetic appeal to effortlessly reflect your brand credentials.

Benefits

  • Modern and slim design – robust yet elegant allowing for an unobtrusive integration into any application and environment.
  • Secure remote management – control your devices remotely and securely using NaviSet Administrator 2; proactively manage maintenance requirements saving time and resources.
  • Unhindered readability – no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation.
  • Mission-critical 24/7 ready operation – the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.
  • Future Ready Connectivity – featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.

Screen Size
75 inch
Panel Technology
IPS with Direct LED backlights
Max. Resolution
3840 x 2160 pixels
Max. Brightness (average)
500 cd/m2
Contrast Ratio
8000:1
Viewing Angle (H/V)
178
Response Time
8ms
Panel Refresh Rate (Hz)
60Hz
Haze Level (%)
25
Supported Orientation
Landscape, Portrait
Dimensions (W x D x H) (display only)
1682.3 x 83.2 x 961.1 millimetre
Bezel Width
14.3 (left, right & top); 14.8 (bottom) millimetre
Weight
38 kilogram
VESA Mounting [mm]
4 holes M8 600 x 400 (FDMI)
Horizontal Frequency [kHz]
15 - 135
Vertical Frequency [Hz]
23-76
Native Resolution
3840 x 2160 pixels
Aspect Ratio
16:9
Supported Resolution
1920x1080, 3840x2160, 1024x768, 1920x1200, 4096x2160, 1280x720, 1366x768, 1280x1024, 1440x900, 1600x1200, 1650x1050, 2560x1600, 1920x2160
Input Video Digital
1 x Display Port (with HDCP) 2 x HDMI (with HDCP)
Input Audio Digital
1 x Display Port 2 x HDMI
Input Control
LAN 100Mbit Remote control wire (3.5mm jack), RS232
Input Data
1 x USB 2.0 (Downstream) 1 x USB 2.0 (Powered 5V/2A, Firmware Updates) 1 x USB 2.0 Type-B (Downstream)
Output Video Digital
1 x HDMI (loop through: HDMI, SDM slot-in PC) 1 x DisplayPort (loop through: DisplayPort, SDM slot-in PC) DP (in) to HDMI (out) conversion
Compute Module Slot
RPi4 Compute Module
Intel SDM
Accepts Intel® Smart Display Modules Large and Small up to 66W
Installation

Landscape
Portrait

Ambient Light Sensor
Integrated triggered actions programmable
Temperature Sensor
Integrated 3 sensors Triggered actions programmable
Power Consumption
200-300W
Power Savings Mode
<0.5W (Normal Standby); 2W (Network Standby)
Operating Hours
24/7
Operating Temperature
0ºC to 40ºC
Operating Humidity
20% to 80%
Storage Temperature
-20ºC to 60ºC
Storage Humidity
10% to 90%
Special Characteristics
DICOM Simulation; HDMI ARC; Powered USB Port (10 W); Removable Logo
Certificates
Energy Star 8.0, RCM, EMC Class B, PSB, UL/C-UL, VCCI
Audio (Speakers)
Integrated Speakers (10W + 10W), Integrated Audio Amplifier (for optional speakers up to 2 x 15 W)
Shipping Content (Accessories)
HDMI Cable, Power Cable, Remote Control, 2x AAA Batteries, Setup Manual
External Control
AMX NetLinx Support, ASCII Control Commands, Crestron Connected, HDMI CEC, HTTP Browser, PJLink, Scheduled Timer, SNMP
Remote Management
Automated Email Alerts, NEC NaViSet Administrator 2
Security
Disable HW Buttons, Disable IR Functionality, Emergency Notification
